3D printing_Product_Zhejiang TOP Environmental Technology Co., Ltd

Inert powder mixer CS

TBD1001

Inert powder mixer CS

Inert gas powder mixer is widely used in 3D printing, pharmaceutical, food, coating, building materials, chemical industry and other industries, the equipment can be according to the user's product process for single powder, granular material or a variety of powder mixing, to meet different product process and production needs. Powder material is uniform distribution, the better performance of product quality, the mixer adopts hopper to turn 360 °, and 30 ° to the driven rotary axis, powder will be 360° free fall and roll, at the same time do high speed tangential motion along the hopper bucket wall, With the square cone hopper and 30° Angle design can make the material in the rolling and tangential movement, impact, bumping, diversion more intense,, reach the best mixing effect. In order to better ensure the powder, granular material physical properties and chemical properties do not change in the process of mixing, the device is equipped with inert gas protection function, input the inert gas mixing hopper, and oxygen content of sensors to monitor the oxygen value inside the hopper, ensure material in the process of mixing environment remain the inert gas in the hopper, the material will not be oxidation or other microscopic chemical reaction.

Inert powder mixer

TBD100

Inert powder mixer

Inert gas powder mixer is widely used in 3D printing, pharmaceutical, food, coating, building materials, chemical industry and other industries, the equipment can be according to the user's product process for single powder, granular material or a variety of powder mixing, to meet different product process and production needs. Powder material is uniform distribution, the better performance of product quality, the mixer adopts hopper to turn 360 °, and 30 ° to the driven rotary axis, powder will be 360° free fall and roll, at the same time do high speed tangential motion along the hopper bucket wall, With the square cone hopper and 30° Angle design can make the material in the rolling and tangential movement, impact, bumping, diversion more intense,, reach the best mixing effect. In order to better ensure the powder, granular material physical properties and chemical properties do not change in the process of mixing, the device is equipped with inert gas protection function, input the inert gas mixing hopper, and oxygen content of sensors to monitor the oxygen value inside the hopper, ensure material in the process of mixing environment remain the inert gas in the hopper, the material will not be oxidation or other microscopic chemical reaction.

Inert powder packing machine

TGB800

Inert powder packing machine

Inert powder packing machine is widely used in 3D printing, pharmaceutical, chemical and other industries, the equipment with inert protection circulation, clean O₂ steam, and other organic gases, for packing powder and granule materials prevent from oxidation or chemical reactions , extend the storage time of powder. For example 3D printing industry adopted by the metal aluminium powder, titanium powder, etc., if directly exposed to the air for filling and sealing, aluminium powder or titanium powder between the gap will be filled with air, will be oxidation after a period of time, as well as adsorption of water vapor in the air, make powder binder into pieces or group, will affect the quality of 3D printing finished workpiece. The equipment with inert protection function, can monitor the packing chamber pressure and oxygen content in real time, to ensure that the powder and granule material are packaging in inert environment, materials will not be oxidation, can be stored for a long time without changing its physical and chemical properties.

Powder conveyor sieving station

TVS-400

Powder conveyor sieving station

TVS-400 series is a combination of powder conveyor andsieving station, used for explosive metal powder reclaim purpose in safe working area. Lots of Titanium and Aluminium powder can be considered to be recycled for re-use after 3D printing finished. During the sieving job processing, the sieving inside environment have to be considered as a hazardous area Zone 20, thus explosion proof is necessary for this powder　sieving machine.

Powder supply change station

TCS-2

Powder supply change station

AM parts powder removal system

TCB-100 Powder cleaning station

AM parts powder removal system

This series of equipment is mainly used in safe area to clean the residual powder of 3D printing parts in a complex geometric path, which is difficult to clean by conventional technology. Metal powders are usually flammable and explosive, so explosion protection is a necessary performance of the equipment.This series of equipment has been certified by a third-party authorized body.

Sieving station

TSF-400

Sieving station

This machine used for powder reclaim purpose. Lots of Titanium and Aluminium powder can be considered to be recycled for re-use after 3D printing finished. During the sieving job processing, inside environment have to be considered as a hazardous area zone 20, explosion proof is necessary.

Powder conveyor

TVC-250E

Powder conveyor

This machine used for powder collect purpose.Lots of Titanium and Aluminium powder can be considered to be recycled for re-use after 3D printing finished. During the recycle job processing, the printer inside environment have to be considered as a hazardous area Zone 20, explosion proof is necessary for this powder conveyor.

Matal 3D printing air circulation filtration system

TAF-10

Matal 3D printing air circulation filtration system

This product is mainly used to collect and purify dust produced by laser sintering in the process of metal 3D printing. For getting a better workpiece during metal 3D printing, the finer the powder is, the better the performance will be. Different size of dust will be produced, so the single filter is very difficult to handle dust, based on the machine three level filtration design, different powder use different filter, make filter a longer life. Dust with large particle size is buried by sand, and dust with easy spontaneous combustion is neutralized by liquid inertness to ensure explosion safety.
