TDC1-MEX SERIES
MOBILE DUST COLLECTOR
TDC1-M mobile dust collector is specially designed for gas hazardous area ZONE 1 ZONE 2 and dust hazardous area ZONE 21 ZONE 22, can be used for variety of explosive dust collection and filtration.
- Description
- Specifications
- Video
-
- Commodity name: MOBILE DUST COLLECTOR
- Commodity ID: TDC1-MEX SERIES
TDC1-M mobile dust collector is specially designed for gas hazardous area ZONE 1 ZONE 2 and dust hazardous area ZONE 21 ZONE 22, can be used for variety of explosive dust collection and filtration.
-
INTRODUCTION TDC1-M mobile dust collector is specially designed for gas hazardous area ZONE 1 ZONE 2 and dust hazardous area ZONE 21 ZONE 22, can be used for variety of explosive dust collection and filtration.
The whole machine is explosion-proof structure designed, integrated structure, Plug-and-Play, convenient and fast installation. With certified explosion proof blower.Explosio proof certified blower.Equipped with antistatic nano fiber flame retardant filter cartridge, whole machine is antistatic bonded with grounding pole, grounding clamp is optional, to ensure that the grounding resistance of the whole machine is less than 10Ω.Explosion proof control switch and other EX rated parts are adoptedEquipped with a mechanical magnehelic gauge, which can be used to determine whether it is necessary to reverse purge or replace the filter cartridge according to the pointer area of the magnehelic gauge.Stailess steel housing is optional.Manual button compressed air pulse cleaning mode, pulse cleaning system electrical components are explosion-proof typesThe clamping slot of the end cover is placed inside the protective door to avoid leakage if caused by the deformation of the end cover placed on the ground.APPLICABLE FIELDS
NEW MATERIALNEW ENERGYFOOD &
PHARMACEUTICALELECTRONICSPRECISION
MANUFACTURINGWORKING PRINCIPLE ■ Dust and fumes are captured by the extractor arm or pipeline and enters the filter chamber under the power of the blower. When it passes through the horizontally placed cartridge, the particles are filtered and the clean air penetrates the filter material into the center of the cartridge, directly output indoor through the clean air chamber by blower.
■ With the accumulation of dust on the surface, the pressure difference will be gradually increased, which is directly shown in the magnehelic gauge. According to the instructions of magnehelic gauge, manual button pulse cleaning can be carried out to make the dust on the surface of the cartridge fall off to the dust bin.
TECHNICAL DATA TYPE TDC1-MEX TDC1-MEXS Ex markEx dem IIC T4 Gb/Ex tD mD A21 IP65 T130℃Housing constructionPlastic sprayed carbon steelSUS 304Related voltage(V)380V，3P/N/PERelated Frequency(Hz)50Hz Power input(kW)1.5 Max airflow(m³/h)1500 Max pressure(Pa)2250 Capacity(L)12.8 Cartridge quantity(pcs)1 Filtration area (m²)15 Filter degreeH13 Dust cleaningManual pulse cleaningCompressde air required4-5bar clean and dry compressed airInput pipe size(mm)200 APPLICATION PROCESS
-
