Products
TVT Series
Venturi wet type dust collector
Integrated overhead blower, built-in cyclone, can effectively produce high-speed cyclone, promote the separation of air and liquid, the circulating water tank has high and low level detection and alarm, low level automatic electromagnetic water supply, high level overflow port.
- Description
- Specifications
- Video
-
- Commodity name: Venturi wet type dust collector
- Commodity ID: TVT Series
Integrated overhead blower, built-in cyclone, can effectively produce high-speed cyclone, promote the separation of air and liquid, the circulating water tank has high and low level detection and alarm, low level automatic electromagnetic water supply, high level overflow port.
INTRODUCTION ■ Automatic Water Circulation System
Built-in cyclone separator effectively generates high-speed swirling flow to enhance gas-liquid separation. The circulation water tank is equipped with high/low water level detection and alarms, automatic electromagnetic freshwater replenishment at low water levels, and an overflow port at high water levels.■ Stable Operation & Long-Term Durability
No filter cartridges required, no clogging, no replacement of filter media. The washing liquid is recyclable with minimal discharge. Constant air volume and dust removal efficiency.■ HEPA Module Option
High separation efficiency (post-treatment emission concentration for general dust <20mg/m³). A HEPA module can be added at the exhaust outlet to meet stricter emission concentration requirements.■ High-Efficiency Dust Removal
Reliably solves challenges of sticky, oily, and humid smoke/dust. Specifically addresses removal of highly reactive, flammable, explosive dust or high-temperature flue gas.■ Modular Design
Space-saving, zero risk of secondary dust emission, and strong versatility.■ Explosion-Proof Design
Wet dust collectors uniquely excel in handling highly reactive metal dust. Dust entering the system is submerged and inertized by liquid, isolating it from air to eliminate ignition risks. Equipped with explosion-proof blowers and related explosion-proof electrical components.■ Standard Features
Casing material: Carbon steel
Circulation pump, water circuit, startup control box
Standard color: RAL7035
Water pressure monitoring, water flow monitoring
Maintenance door
Manual sludge discharge valve, sludge bucket
Float-type liquid level gauge (with level sensor), electromagnetic liquid replenishment valve
■ Optional FeaturesStainless steel 304/316L
Top-mounted blower
Explosion-proof options (for explosive dust)
Outdoor freeze-proof configuration
Automatic sludge discharge valve
VFD frequency control cabinet
High-temperature flue gas treatment configuration
Ultrafine dust treatment configuration
Auto-adjustable venturi throat device
Internal anti-corrosion paintAPPLICABLE FIELDS AEROSPACENEW ENERGYFOOD &
PHARMACEUTICALCHEMICAL PROJECTELECTRONICSWORKING PRINCIPLE ■ Under the negative pressure of the blower, the dusty air enters the wet dust collector through a tangential venturi inlet.
■ The liquid is shot into the venturi inlet through a nozzle port. Under the action of venturi, the liquid atomization is fully mixed with the air stream, and the pollutants in the air stream are absorbed and captured. The liquid containing pollutants is separated from the air stream. The muddy sediment captured by the water settles into the circulating tank in layers.
■ The purified air is output through the blower.
APPLICATION PROCESS
-
TECHNICAL DATA TYPE TVT2.4 TVT3.6 TVT5.6 TVT8.0 Protection degreeIP54 Rated power(kW)4 5.5 11 15 Rated voltage(V)380 Rated frequency(Hz)50 Designed airflow(m³/h)2600 3600 5600 8000 Water capacity(L)400 480 600 960 Outer negative pressure(Pa)700 800 1000 Cleaning wayDust binSound level(dB)≤75 ≤77 ≤78 Diameter/Height700/2900 800/3170 1120/3530 1300/4100 -
