THV-800/1200 SERIES

HIGH VACUUM DUST COLLECTOR


As an industrial grade dust removal equipment,High vacuum dust collector is specially used to collect and purify dry smoke and dust without oil. It is widely used in welding,cutting, grinding and other mechanical processing as well as pharmaceutical industry, local cleaning and other industrial environments.

  • Description
  • Specifications
  • Video
    • Commodity name: HIGH VACUUM DUST COLLECTOR
    • Commodity ID: THV-800/1200 SERIES

    As an industrial grade dust removal equipment,High vacuum dust collector is specially used to collect and purify dry smoke and dust without oil. It is widely used in welding,cutting, grinding and other mechanical processing as well as pharmaceutical industry, local cleaning and other industrial environments.

    INTRODUCTION

    · Variable Frequency Side Channel Vortex Blower

    The use of a variable frequency side channel vortex blower enables the dust collector to generate a negative pressure exceeding -20 kPa and a maximum airflow of 1,600 m³/h. It is compatible with piping systems, quick-connect couplings, suction hoses, and other accessories. This setup allows source capture of smoke and dust across large areas and multiple workpoints.



    · Siemens PLC Control System and Siemens Touch Screen

    Equipped with a Siemens PLC control system and Siemens touch screen, combined with remote sensors, the system automatically activates the dust collection system based on the opening/closing of terminal suction ports. The blower’s frequency is automatically adjusted according to the number of open/closed suction ports to meet varying airflow demands. The real-time status of all suction ports and key system parameters are displayed on the touch screen for operator monitoring. The system provides alarms for overload, abnormal pressure, and full dust bins.



    · Shutdown Pipeline Cleaning Function

    The system is equipped with a shutdown pipeline cleaning function. When the system is shut down, the main pipeline cleaning valve opens to flush the main pipeline with high-speed airflow, preventing dust accumulation.

    · Compressed Air Automatic Dust Cleaning System
    The system includes a compressed air automatic dust cleaning system using online cleaning to ensure uninterrupted operation. The cleaning system can switch between two modes: differential pressure-controlled automatic cleaning and time-based automatic cleaning.

    APPLICABLE FIELDS








    AEROSPACE
    NEW ENERGY
    FOOD &
    PHARMACEUTICAL
    NEW MATERIAL
    ELECTRONICS

    WORKING PRINCIPLE


    The dusty air flow enters the cylindrical filter chamber at high speed along the tangent direction the large dust or welding slag settles into the barrel along the wall of the cylinder,The fine dust will be intercepted by the high efficiency filter when the airflow passes through the surface of the filter cartridge.Clean air flows into the blower from the inner wall of the filter cartridge and is discharged into the roomEmissions to the outside of the machine.

    Dust collector is equipped with compressed air pulsating dust-cleaning systemIt can switch between differential pressure control automatic dust cleaning and Timing control automatic dust cleaning at any timekeep the good working condition of the

    filter cartridge.







    APPLICATION PROCESS



  • TECHNICAL DATA
    TYPEHTV-800THV-1200
    Protection degree
    IP55
    Rated power(kW)
    1118..5
    Rated voltage(V)
    380380
    Rated frequency(Hz)
    5050
    Max airflow(m³/h)
    12001600
    Max pressure(KPa)
    -29-32
    Working data(m³/h@KPa)
    800@-241200@-22.5
    Capacity(L)
    60100
    Cartridge quantity(psc)
    12
    Filtration area(m²)
    1114
    Blower type
    Side channel high pressure blower
    Filter degree
    H13
    Dust cleaning
    Compressed air pules cleaning
    Suction inlet size(mm)
    100125
    Sound level(dB)
    74
